Curved / Special-Shaped Display
// 50" TFT-LCD
// Touchscreen (Capacitive)
// Power Supply DC 24V
Sales only to business customers.
Delivery time: upon request
Basic Module: Winmate W50L100-POCV
| General information | ||||
| SKU / Item Number | W50L100-POCV | |||
| Product Basic Data | ||||
| Manufacturer | Winmate | |||
| Display | ||||
| Display Typ | 50" TFT-LCD | |||
| Max. Resolution | 3840 x 2160 | |||
| Aspect Ratio | 16 : 9 | |||
| Contrast | 4000:1 | |||
| Luminance | 425 cd/m² | |||
| Viewing angle | Horizontal | 178 ° | ||
| Vertical | 178 ° | |||
| Backlight | Type | LED | ||
| Touch Screen | Type | Capacitive | ||
| Externe I/O (Rear Panel) | ||||
| Display | HDMI | 1 Pce | ||
| DVI | DVI-D signal | 1 Pce | ||
| DisplayPort | 2 Pce | |||
| Power Supply | ||||
| Typ (Input) | DC | Wide Range | No | |
| Range | 24V | |||
| Connector | DC Power Jack | |||
| Power supply - Input | DC: 24V | |||
| Mechanical / Environment | ||||
| Temperature | Operation | 0° to 50°C | ||
| Storage | -10° to 60°C | |||
| Relative humidity | Operation | 10 to 90%, non-condensing | ||
| Dimensions | Form factor | 50" | ||
| Width | 1.153 mm | |||
| Deep | 164 mm | |||
| Height | 679 mm | |||
| Controls | Power | 1 Pce | ||
| Color | Black | |||
| Material | Steel | |||
| Mounting option | VESA | |||
| Certificates / Conformities | ||||
| CE | Yes | |||
| FCC | Class A | Yes | ||
| RoHS compliant | Yes | |||
We are happy to advise you personally.
