Avalue introduces ERX-W480P, an Micro ATX motherboard

Avalue, Taipei, Taiwan, 20.06.2022 - Avalue Technology Inc. (TAIEX: 3479-TW), a global industrial PC solution provider and an associate member of the Intel® Internet of Things Solutions Alliance, is unveiling ERX-W480P, based on Intel®10th Generation Core™ and Celeron® Processors.

ERX-W480P, a Micro ATX board with 10th Gen Intel® Core™ i3/i5/i7 and Celeron® SoC Processor, which has a rich IO and dual channel LVDS industrial motherboard requires less expansion application for Automation, Industrial, Automatic Medicine Packing Machine and other embedded applications.

ERX-W480P Main Features

• Intel® LGA1151 Socket Supports 10th Gen. Core™ i7/ i5/ i3, Pentium® and Celeron® Processors (Max. TDP at 125W)
• Four 288-pin DDR4 U-DIMM Socket, Supports Up to 128GB Max (ECC memory supported by CPU)
• DDR4 2933MHz (W1290E /W1290TE /W1270E /W1290TE /i9 /i7 CPU) /
• DDR4 2666MHz (W1250E /W1250TE /i5 /i3 CPU) /
• DDR4 2400MHz (Pentium / Celeron CPU)
• 1 x VGA, 1 x HDMI, 1 x DP++/2CH LVDS
• 1 x Intel® i210AT, 1 x Intel® i219LM Gigabit Ethernet, 2 x Intel® I225LM 2.5 Gigabit Ethernet Controller, 1 x Intel® X550-AT2 10GBase-T LAN (BOM optional)
• 4 x USB 3.1 Gen1 at I/O
• Internal USB: 2 x USB 3.2 Gen1, 7 x USB 2.0, 1 x USB 2.0 Vertical type A
• 4 x RS-232, 4 x RS-232(By BOM optional), 2 x RS-232/422/485, 16-bit GPIO
• 4 x SATAIII
