Avalue launches the latest Hybrid design 3.5-inch embedded SBCs: ECM-ADLS

Avalue, Taipei, Taiwan, 03.08.2023 - Avalue Technology Inc. (TAIEX: 3479-TW), a global industrial PC solution provider and a Titanium member of the Intel® Internet of Things Solutions Alliance, is proud to introduce ECM-ADLS, its latest 3.5-inch single board computer. It supports not only Intel® 12th Generation Core™ i7/i5/i3/Pentium®/Celeron® processors, but also Intel® 13th Gen i5/i3 processors LGA 1700 CPUs up to 35W. The S-series processors feature a new hybrid design that combines Performance-cores and Efficient-cores for multi-threaded performance, delivering a superior experience for gaming, content creation, virtual reality, retail terminals, digital security systems, healthcare, and more.

The ECM-ADLS, a 3.5-inch single board computer, features supporting for both Intel® 12th & 13th generation processors with LGA 1700 CPU socket, which is the first Avalue 3.5" SBC to incorporate DDR5 design. It also offers extensive I/O support, including 4 x USB 3.2, 4 x USB 2.0, 2 x COM, 1 x 8-bit GPIO, 2 expansion M.2 slots: E key support 2x PCIe x1 Gen 3, USB 2.0 for Wi-Fi module connection, M key support PCI-e x 4 Gen 3 NVMe or SATA device for storage, 2 high-speed 2.5G Ethernet transmission.

In addition, ECM-ADLS supports triple display: 1 x HDMI, 1 x DP and also 18/24-bit 2-CH LVDS or eDP share the same connector by BIOS selection (default LVDS). With its impressive features and robust performance, ECM-ADLS proves to be a versatile and reliable choice for retail, automation, vending machine, POS/KIOSK, signage and industrial transportation applications.

ECM-ADLS main features

• Intel® 12th Gen Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor, supports LGA 1700 CPU Up to 35W Max
• Intel® 13th Gen Core™ i5/i3 Processor, supports LGA 1700 CPU Up to 35W Max
• Intel® Q670E/H610E chipsets
• Single 262-pin DDR5 4800MHz SO-DIMM socket, support up to 32GB
• Triple Display: 1x DP++, 1x HDMI, 1x 2CH LVDS or 1x eDP (default LVDS)
• Expansion Slot: 1x M.2 Key-E, 1x M.2 Key-M
• 2x RS-232/422/485, 4x USB 3.2 Gen 2 (note: H610E USB 3.2 Support 2x Gen 2 & 2x Gen 1), 4x USB 2.0
• Two Intel® Gigabit Ethernet: 2x 2.5GbE (I226LM)
• Realtek ALC888S Audio Codec
• DC +12V Voltage Input
