Avalue Unveils ECM-EHL3, 3.5" Embedded SBC with Abundant I/O Connectivity

Avalue, Taipei, Taiwan, 29.06.2023 - Avalue Technology Inc. (TAIEX: 3479-TW), a global industrial PC solution provider and a Titanium member of the Intel® Internet of Things Solutions Alliance. Avalue is proud to announce the launch of the new 3.5” embedded single board computer, ECM-EHL3, powered by Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor (Elkhart Lake Platform 4.5~12W), CPU bottom mounted, with enhanced performance and Intel® UHD Graphics. Targeting the entry-level application market, the ECM-EHL3 comes with rich I/O capabilities and advanced security features, making it an ideal choice for industrial automation, retail, smart city, IoT solutions, etc.

The 3.5” SBC ECM-EHL3 features flexible I/O, including 2 USB 3.1 Gen.2, 6 USB 2.0, 2 RS-232/422/485, 4 RS232 and a wide DC power input range of 9~36V. It supports triple display: Dual DP, LVDS/eDP for various industry applications. ECM-EHL3 is designed with three M.2 expansion slot, enabling extensive expansion such as M.2 E-Key PCIe/USB for Wifi module connection, M.2 B-Key SATA/USB, supporting WWAN+GNSS or storage, and M.2 M-Key PCIe for storage. In addition, the three Ethernet ports, dual 1GbE & one 2.5GbE Intel® Gigabit Ethernet ensure high speed and reliable Ethernet connection, perfectly suited for most industrial applications.

ECM-EHL3 Main Features

• On board Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor (Elkhart Lake Platform 4.5~12W) (with CPU Bottom Mounted)
• Single 260-pin DDR4 SODIMM Socket, Supports Up to 32GB DDR4 3200MTs SDRAM (non ECC Supported)
• Triple Display (2 DP++, LVDS/eDP, default LVDS)
• Flexible I/O support with rich expansion Slot, 1xM.2 Key B, 1xM.2 Key-E, 1xM.2 Key-M
• Three Gigabit Ethernet: 1 x 2.5GbE (I226LM), 2 x 1GbE (I210AT)
• Dual Intel® Gigabit Ethernet, 2.5GbE, 1GbE
• 9V~36V Wide Range Voltage Input
• TPM 2.0

ECM-EHL3 Main applications

• Industrial and Factory automation
• Retail, Digital Signage, KIOSK
• Infotainment
