MX610H Value-Performance Optimized Mini-ITX Motherboard Now Shipping!

BCM, USA, 04.01.2023 - Our new MX610H industrial Mini ITX motherboard is designed based on the latest 12th Gen Intel® Core™ Processor family codenamed Alder Lake. Alder Lake is the first Intel® Core™ processor to feature performance hybrid architecture combining Performance-Cores and Efficient-Cores with Intel® Thread Director to deliver intelligent workload optimization. The board is built with Intel® H610E PCH and the LGA1700 CPU socket which supports the 12th Gen Intel® Core™ i9/i7/i5/i3 processors and delivers scalable computing performance.

The MX610H is based on the Alder Lake “H-Series” PCH offering exceptional value-performance. The board is a great solution for applications that require high performance computing without some of the features offered in the Alder Lake “Q-Series” PCH.

Product Design Features

Gen4 PCIe, DDR5, USB, M.2

• Supports DDR5 4800MHz up to 64GB. Gen4 PCIe x16, 2 M.2 supports NVMe and CNVi. 6 USB 3.2 Gen 1x1, 6 USB 2.0. 2 COM, 3 SATA III.

Supports 3 Independent Display

• HDMI, 2 x DP++ 1.4a 4K, 18/24-bit LVDS, optional eDP.

ATX Power

• The MX610H uses ATX power so is capable of supporting most high performance GPUs with its PCIe x 16 expansion slot while still maintaining a small overall footprint.

Target Customers/Applications

• Test Instruments, Measurement Devices, Inspection Devices
• Interactive Kiosk, Retail Kiosks, Self-serve Kiosks
• Industrial controller Box PC, Irrigation System Controllers

Need a compatible chassis?

For added convenience and to help speed our customers’ time to market, BCM also provides BI360-610H, with the MX610H motherboard inside an enclosure and power supply as a system level building block. The BI360 chassis provides a riser card option for a PCIe x16 expansion slot.

Visit BI360-610H product page for more information.
